| ELECTRICAL SPECIFICATIONS: | |
|---|---|
| FREQUENCY | 1616 - 1626.5 MHz (L-Band) |
| SATELLITE SYSTEM | Iridium |
| IMPEDANCE | 50 ohm |
| POLARISATION | RHCP (SAT) |
| AXIAL RATIO | < 6 dB |
| GAIN | 2 dBic |
| VSWR | < 2.0 |
| MECHANICAL SPECIFICATIONS: | |
|---|---|
| COLOR | Glossy White |
| HEIGHT | 111 mm |
| DIAMETER | 94 mm |
| WEIGHT | 300 g |
| MOUNTING | 1" thread (US)(1"-14NF) |
| OPERATING TEMPERATURE | -25C to +55C |
| SURVIVAL TEMPERATURE | -40C to +80C |
| CONNECTOR 1 | TNC (f) (SAT) |
| CABLE | Not included |
| MOUNTING PLACE | On pole using bracket |
| INGRESS PROTECTION | IP66 |
| VIBRATION | IEC60945 |
| ORDERING INFORMATION: | |
|---|---|
| PART NO. | 65900 |
| PRODUCT TYPE | SATELLITE PHONE |
|---|---|
| USE TYPE | FIXED, MARITIME |
| BRAND | SCAN ANTENNA |
| PART # | 65900-003 |
| NETWORK | IRIDIUM |
| USAGE AREA | 100% GLOBAL |
| FEATURES | PASSIVE |
| HEIGHT | 111 millimètres |
| DIAMETER | increased to 94 million |
| WEIGHT | 300 grammes |
| FREQUENCY | L BAND (1-2 GHz) |
| ACCESSORY TYPE | ANTENNA |
| INGRESS PROTECTION | IP 66 |
| OPERATING TEMPERATURE | -25°C to 55°C (-13°F to 131°F) |
| SURVIVAL TEMPERATURE | -40° to 80°C (-40° to 176°F) |
| CERTIFICATIONS | IRIDIUM CERTIFIED |
